Home > Simrad NSX3015UW 15in MFD with Active Imaging Transducer

Simrad NSX3015UW 15in MFD with Active Imaging Transducer

$4,436.25
Simrad
SIM00016213001
Add to Cart

Simrad NSX 3015UW Ultra Wide 15" MFD

Model: 000-16213-001
  • NSX ULTRAWIDE delivers all the benefits of multiple displays, without the hassle of multiple installations
  • Fewer cables
  • One cutout
  • Less setup
  • Condenses the same wealth of information from two screens into one, delivering a seamless and fully immersive user experience - all thanks to the new cutting-edge ultrawide aspect ratio and high-pixel density display.
  • The panoramic display compliments the aesthetics of your boat designs, letting you create eye-catching, low-profile dashboards straight out of the luxury auto world.
  • Information that is more consumable
  • More screen, less space
  • Simplified installation
  • Unique screen format — new to marine
  • Better viewability
  • Enables automotive-style dash designs

The current square display format limits visibility and functionality, especially with charts and when using split screens to view multiple apps. As a result of wasted space and visual imbalances, existing displays often fail to deliver a clean and sleek dash aesthetic. The installation of multiple screens slows down production. The additional dash modifications, cabling, and setup consume additional installation time. It’s simply inefficient.

The new NSX ULTRAWIDE, the next step in the NSX platform evolution. Revolutionary 12" and 15" ultrawide marine MFDs, setting a new standard in the market. NSX ULTRAWIDE offers consumers enhanced visibility, control, and functionality. OEMs can deliver a unique, premium aesthetic, and all the advantages of dual displays, with none of the hassle. NSX ULTRAWIDE offers the same active area as two smaller displays. But, in terms of functionality, ULTRAWIDE offers so much more. It condenses the same wealth of information from two screens into one, delivering a seamless and fully immersive user experience - all thanks to the new cutting-edge ultrawide aspect ratio and high-pixel density display.

Specifications
Display
Size and Type15" SolarMax IPS Touchscreen display for wide viewing angles, extreme clarity and sunlight viewability with polarized sunglasses
Resolution1920 x 720 px
Viewing Angles85° (top, bottom, left, and right)
Screen Brightness>1000 nits
Backlight ColorWhite
Power
Supply Voltage12 V DC (10 - 17 V DC min - max)
Power Consumption max25 W (1811 mA at 13.8 V)
ProtectionReverse polarity and over voltage (Max 18V)
Recommended Fuse Rating3A
Physical
Dimensions No Bracket, no suncoverW: 390.0 mm (15.55") x H: 170.4 mm (6.71") x D: 88.5 mm (3.48")
-With gimbal bracketH: 180. mm (7.10") D:96.5 mm (3.80")
MountingTypeRear mount (bracket supplied), Bracket mount (bracket optional)
Compass Safe Distance50 cm (1.7 ft)
Environmental
Operating Temperature Range-15°C to 55°C (5°F to 131°F)
Storage Temperature Range-20°C to 60°C (-4°F to 140°F)
Waterproof ratingIPx6 and IPx7
HumidityIEC 60945 Damp heat 66°C (150°F) at 95% relative (18 hr)
Shock Vibration100,000 cycles of 20 G
Interface and connections
InterfaceMulti-touch screen
Sonar CompatibilityOne 9 pin Xsonic 1 kW Sonar port. Single channel CHIRP, 50/200 KHz, SideScan & DownScan upto 800 KHz, Network sonar modules S3100, S5100.
Ethernet1 port (5-pin connector) Radar Compatibility: Halo Dome radars, Halo open array radars, 3G/4G, HD Radars
WeatherNot in first release
USB1 port (USB A) Output: 5 V DC, 1.5 A
External Storage1 MicroSD slot, 1 port (USB A)
NMEA 20001 x NMEA 2000 Micro-C port, 1 LEN
NMEA 0183No
GPSInternal, 10Hz, WASS, MSAS, EGNOS
GPS Correction10 Hz high speed update (internal) WASS, MSAS, EGNOS, GLONASS
GPS Position AccuracyHorizontal Accuracy 3 m (9.8 ft)
GPS Receiver Channels32 Channels
GPS Update rate10Hz
J1939No
WiFiIEEE 802.11b/g/n
BluetoothBluetooth 4.0 with support for Bluetooth Classic
Charts SupportedC-MAP Discover X, C-MAP Reveal X, third party charts
AISReceive AIS data over NMEA 2000
Digital SwitchingC-Zone, Simrad COMMAND DDS
Warranty
Warranty Period2 Years

What's in the Box:
  • NSX3015UW Display
  • ActiveImaging™ 3-IN-1 Transducer w/ 7.6m (25ft) cable
  • DISCOVER X - NORTH AMERICA
  • 4-Pin Power Cable
  • Fuse Kit
  • NSX 3015UW Suncover
